Motorcycle Transport Crate
Technical drawing with dimensions — use this to get a quote from a metal fabricator
↔
240 cm
Length
↕
80 cm
Width
↑
120 cm
Column Height
Specifications: Steel welded frame structure. Base platform: 240×80 cm with steel mesh flooring. 4 corner columns at 120 cm height with top goal-post cross bars for rigidity. Central fork stabilizer bar. Bottom forklift entry tubes. Recommended finish: powder coated (RAL 5010 blue or as required).
